| Varenummer | AC121SA01 |
| Mærke | Mitsubishi |
| Størrelse | 12.1 |
| Ansøgning | IA |
| Løsning | 800×600 |
| Sammensætning | LCM |
| Lysstyrke | 450 |
| CR | 800:1 |
| Farver | 262K/16.7M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | Mitsubishi |
| panel model | AC121SA01 1 Compatible model |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 12.1 inch |
| løsning | 800(RGB)×600 , SVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 246×184.5 mm |
| omrids | 260×203×10 mm |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | 450 cd/m² (Typ.) |
| kontrastforhold | 800:1 (Typ.) |
| vise farver | 262K/16.7M (6-bit / 6-bit + Hi-FRC), CIE193172% |
| responstid | 4/12 (Typ.)(Tr/Td) |
| synsvinkel | 80/80/60/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDEmbedded (LED Driver) |
| signal interface | LVDS (1 ch, 6/8-bit), 20 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | IA |
| AA121TD01 | Mitsubishi | 12.1 | 1280×800 |
| AA121TH11-DE1 | Mitsubishi | 12.1 | 1280×800 |
| AC121SA01 | Mitsubishi | 12.1 | 800×600 |
| AC121SA02 | Mitsubishi | 12.1 | 800×600 |
| G121X1-L04 | Innolux | 12.1 | 1024×768 |
| HV121WX4-120 | HYDIS | 12.1 | 1280×800 |
| HV121WX5-120 | HYDIS | 12.1 | 1280×800 |
| LP121X1-A2M1 | LG Display | 12.1 | 1024×768 |
| LT121SU-121 | Samsung | 12.1 | 800×600 |
| LTN121W1-L03 | Samsung | 12.1 | 1280×800 |
| AA084VC03 | Mitsubishi | 8.4 | 640×480 |
| AA106TA01 | Mitsubishi | 10.6 | 1280×768 |
| AA121TD01 | Mitsubishi | 12.1 | 1280×800 |
| CLAA057VC01CT | CPT | 5.7 | 640×480 |
| G190EAN01.0 | AUO | 19.0 | 1280×1024 |
| LM10V332 | SHARP | 10.4 | 640×480 |
| LQ084V1DG22 | SHARP | 8.4 | 640×480 |
| LQ104V1DG5A | SHARP | 10.4 | 640×480 |
| NL6448AC33-27 | NLT | 10.4 | 640×480 |
| TX14D11VM1CAA | KOE | 5.7 | 320×240 |
