| Varenummer | AM-1280800P4TZQW-T21H |
| Mærke | AMPIRE |
| Størrelse | 7.0 |
| Ansøgning | Industrial |
| Løsning | 1280×800 |
| Sammensætning | a-Si TFT-LCD, LCM |
| Lysstyrke | |
| CR | 800:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| mærke | AMPIRE |
| model | AM-1280800P4TZQW-T21H |
| diagonal størrelse | 7.0 inch |
| type | a-Si TFT-LCD, LCM |
| pixel format | 1280(RGB)×800 [WXGA] 217PPI |
| konfiguration | RGB Vertical Stripe |
| aktivt område | 149.76(H)×93.6(V) mm |
| omrids dim. | 174(H)×118(V) ×13.63(D) mm |
| bezel område | - |
| behandling | Glare (Haze 0%) |
| luminans | 850 cd/m² (Typ.) |
| kontrastforhold | 800:1 (Typ.) (TM) |
| visningsretning | Symmetry |
| responstid | 35 (Typ.)(Tr+Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10) |
| driftstilstand | SFT, Normally Black, Transmissive |
| støtte farve | 16.7M 50% NTSC |
| lyskilde | WLED [6S4P] , 50K hours , With LED Driver |
| vægt | - |
| designet til | Industrial |
| billedhastighed | 60Hz |
| berøringspanel | PCAP |
| interface type | LVDS (1 ch, 8-bit) , 20 pins Connector |
| Strømforsyning | 3.3V (Typ.) |
| miljø | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| 70WVW2A | SII | 7.0 | 800×480 |
| AA070ME01-DA1 | Mitsubishi | 7.0 | 800×480 |
| AM-1280800N1TZQW-T06H | AMPIRE | 10.1 | 1280×800 |
| AM-1280800N2TZQW-00H | AMPIRE | 10.1 | 1280×800 |
| AM-1280800N2TZQW-T48H | AMPIRE | 10.1 | 1280×800 |
| C070FW02 V0 | AUO | 7.0 | 480×234 |
| C070VVN03.1 | AUO | 7.0 | 800×480 |
| LQ7BW566AH | SHARP | 7.0 | 480×234 |
| NL8048BC19-02 | NLT | 7.0 | 800×480 |
| PM070WM3 | E Ink | 7.0 | 800×480 |
