| Varenummer | B133HAN02.5 |
| Mærke | AUO |
| Størrelse | 13.3 |
| Ansøgning | NBPC |
| Løsning | 1920×1080 |
| Sammensætning | LCM |
| Lysstyrke | 330 |
| CR | 700:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | eDP |
| panel mærke | AUO |
| panel model | B133HAN02.5 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 13.3 inch |
| løsning | 1920(RGB)×1080 , FHD |
| visningstilstand | AHVA, Normally Black, Transmissive |
| aktivt område | 293.472×165.078 mm |
| omrids | 305.35×194.6×2.6 mm |
| form stil | Slim (PCBA Flat, Depth ≤3.2mm) |
| overflade | |
| lysstyrke | 330 cd/m² (Typ.) |
| kontrastforhold | 700:1 (Typ.) |
| vise farver | 262K (6-bit), CIE193172% |
| responstid | 25 (Typ.)(Tr+Td) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDEmbedded (LED Driver) |
| signal interface | eDP (2 Lanes), 30 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | NBPC |
| B133HAN02.0 | AUO | 13.3 | 1920×1080 |
| B133HAN02.1 | AUO | 13.3 | 1920×1080 |
| B133HAN02.5 | AUO | 13.3 | 1920×1080 |
| B133HAN03.0 | AUO | 13.3 | 1920×1080 |
| B133HAT02.5 | AUO | 13.3 | 1920×1080 |
| B133XTN02.1 | AUO | 13.3 | 1366×768 |
| LP133WD2-SLB1 | LG Display | 13.3 | 1600×900 |
| LP133WH1-TLA3 | LG Display | 13.3 | 1366×768 |
| N133BGE-EAB | Innolux | 13.3 | 1366×768 |
| N133HSE-EA3 | Innolux | 13.3 | 1920×1080 |
| B140HAN01.0 | AUO | 14.0 | 1920×1080 |
| B140HAN01.8 | AUO | 14.0 | 1920×1080 |
| B156HAK01.0 | AUO | 15.6 | 1920×1080 |
| B173HTN01.1 | AUO | 17.3 | 1920×1080 |
| HSD140PHW2-A00 | HannStar | 14.0 | 1366×768 |
| HSD173PUW1-A01 | HannStar | 17.3 | 1920×1080 |
| LP133WH2-TLM4 | LG Display | 13.3 | 1366×768 |
| LP154WP3-TLA3 | LG Display | 15.4 | 1440×900 |
| LP173WD1-TLA2 | LG Display | 17.3 | 1600×900 |
| LTN141BT04-001 | Samsung | 14.1 | 1440×900 |
