| Varenummer | B156HAN10.2 |
| Mærke | AUO |
| Størrelse | 15.6 |
| Ansøgning | Laptop Gaming |
| Løsning | 1920×1080 |
| Sammensætning | a-Si TFT-LCD, LCM |
| Lysstyrke | |
| CR | 1000:1 |
| Farver | 1.07B |
| Baggrundsbelysning | WLED |
| Interface | eDP |
| mærke | AUO |
| model | B156HAN10.2 |
| diagonal størrelse | 15.6 inch |
| type | a-Si TFT-LCD, LCM |
| pixel format | 1920(RGB)×1080 [FHD] 141PPI |
| konfiguration | RGB Vertical Stripe |
| aktivt område | 344.16(H)×193.59(V) mm |
| omrids dim. | 350.66(H)×216.15(V) ×3(D) mm |
| bezel område | - |
| behandling | Antiglare, Hard coating (3H) |
| luminans | 500 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) (TM) |
| visningsretning | Symmetry |
| responstid | 9 (Typ.)(Tr+Td); 3 (Typ.)(G to G)(OD) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10) |
| driftstilstand | AHVA, Normally Black, Transmissive |
| støtte farve | 1.07B 100% Adobe RGB |
| lyskilde | WLED , 15K hours , With LED Driver |
| form stil | Slim (PCBA Flat, T≤3.2mm) |
| designet til | Laptop Gaming |
| billedhastighed | 240Hz |
| berøringspanel | Without |
| interface type | eDP (4 Lanes) , eDP1.4 , HBR2 (5.4G/lane) , 40 pins Connector |
| Strømforsyning | 3.3V (Typ.) |
| miljø | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
