| Varenummer | BT156GW01 V.3 |
| Mærke | Innolux |
| Størrelse | 15.6 |
| Ansøgning | NBPC |
| Løsning | 1366×768 |
| Sammensætning | LCM |
| Lysstyrke | 200 |
| CR | 600:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | INNOLUX |
| panel model | BT156GW01 V.3 61 Compatible model |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 15.6 inch |
| løsning | 1366(RGB)×768 , WXGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 344.232×193.536 mm |
| omrids | 359.3×209.5×5.5 mm |
| form stil | Wedge (PCBA Bent, Depth ≥5.2mm) |
| overflade | Glare (Haze 0%), Hard coating (3H) |
| lysstyrke | 200 cd/m² (Typ.) |
| kontrastforhold | 600:1 (Typ.) |
| vise farver | 262K (6-bit), CIE193160% |
| responstid | 8 (Typ.)(Tr+Td) |
| synsvinkel | 40/40/15/30 (Min.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDEmbedded (LED Driver) |
| signal interface | LVDS (1 ch, 6-bit), 40 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | NBPC |
| B156XW02 V3 | AUO | 15.6 | 1366×768 |
| BT156GW01 V.3 | Innolux | 15.6 | 1366×768 |
| BT156GW01 V.4 | Innolux | 15.6 | 1366×768 |
| BT156GW02 V.0 | Innolux | 15.6 | 1366×768 |
| LP156WF1-TLE1 | LG Display | 15.6 | 1920×1080 |
| LP156WH4-TPA1 | LG Display | 15.6 | 1366×768 |
| LTN156AT02-B04 | Samsung | 15.6 | 1366×768 |
| M156B3-L01 | Innolux | 15.6 | 1366×768 |
| NT156WHM-N12 | BOE | 15.6 | 1366×768 |
| NT156WHM-N42 | BOE | 15.6 | 1366×768 |
| B133XW01 V7 | AUO | 13.3 | 1366×768 |
| B133XW07 V2 | AUO | 13.3 | 1366×768 |
| B141EW02 V3 | AUO | 14.1 | 1280×800 |
| B173HW01 V4 | AUO | 17.3 | 1920×1080 |
| LP133WH2-TLM4 | LG Display | 13.3 | 1366×768 |
| LP133WX2-TLD1 | LG Display | 13.3 | 1280×800 |
| LP150E07-TL02 | LG Display | 15.0 | 1400×1050 |
| LTN121AT01-002 | Samsung | 12.1 | 1280×800 |
| LTN140AT07-401 | Samsung | 14.0 | 1366×768 |
| M133NWN1 R0 | IVO | 13.3 | 1366×768 |
