| Varenummer | CLAA370WA03 |
| Mærke | CPT |
| Størrelse | 37 |
| Ansøgning | LCTV |
| Løsning | 1366×768 |
| Sammensætning | LCM |
| Lysstyrke | 500 |
| CR | 1200:1 |
| Farver | 16.7M |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | CPT |
| panel model | CLAA370WA03 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 37 inch |
| løsning | 1366(RGB)×768 , WXGA |
| visningstilstand | MVA, Normally Black, Transmissive |
| aktivt område | 819.6×460.8 mm |
| omrids | 877×516.8 mm |
| overflade | Hard coating (3H), Reflection 3.0% (Max.) |
| lysstyrke | 500 cd/m² (Typ.) |
| kontrastforhold | 1200:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193175% |
| responstid | 8 (Typ.)(G to G) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 16 pcsCCFLEmbedded (Inverter) |
| signal interface | LVDS (1 ch, 8-bit), 30 pins |
| indgangsspænding | 12.0V (Typ.) |
| rohs: | |
