| Varenummer | G075ADE-T01 |
| Mærke | Innolux |
| Størrelse | 7.5 |
| Ansøgning | NBPC |
| Løsning | 1200×900 |
| Sammensætning | LCM |
| Lysstyrke | 120 |
| CR | 85:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | INNOLUX |
| panel model | G075ADE-T01 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 7.5 inch |
| løsning | 1200×900 |
| visningstilstand | TN, Normally White, Transflective |
| aktivt område | 152.4×114.3 mm |
| omrids | 169.7×139.7×6.5 mm |
| overflade | Antiglare (Haze 25%), Hard coating (3H) |
| lysstyrke | 120 cd/m² (Typ.) |
| kontrastforhold | 85:1 (Typ.)(Transmissive)4:1 (Typ.)(Reflective) |
| vise farver | 262K (6-bit), CIE193129% |
| responstid | 30/20 (Typ.)(Tr/Td) |
| synsvinkel | 15/15/15/15 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 4S3PWLEDWithout Driver |
| signal interface | TTL (1 ch, 6-bit), 55 pins |
| indgangsspænding | 1.8/9.6/18/-7V (Typ.)(VDD/VAA/VGH/VGL) |
| Ansøgning | NBPC |
