| Varenummer | LC190WH1-TLC1 |
| Mærke | LG Display |
| Størrelse | 18.5 |
| Ansøgning | LCTV |
| Løsning | 1366×768 |
| Sammensætning | LCM |
| Lysstyrke | 300 |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | LG Display |
| panel model | LC190WH1-TLC1 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 18.5 inch |
| løsning | 1366(RGB)×768 , WXGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 409.8×230.4 mm |
| omrids | 430.4×254.6×13.5 mm |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | 300 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 16.7M (6-bit + Hi-FRC) |
| responstid | 1.1/3.9 (Typ.)(Tr/Td) |
| synsvinkel | 85/85/75/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 2 pcsCCFLWithout Driver |
| signal interface | LVDS (1 ch, 8-bit), 30 pins |
| indgangsspænding | 5.0V (Typ.) |
| Ansøgning | LCTV |
| LC185EXE-TEA1 | LG Display | 18.5 | 1366×768 |
| LC190WH1-TLC1 | LG Display | 18.5 | 1366×768 |
| LM185WH1-TLF1 | LG Display | 18.5 | 1366×768 |
| LM185WH2-T2BB | LG Display | 18.5 | 1366×768 |
| LM185WH2-TLA1 | LG Display | 18.5 | 1366×768 |
| LM185WH2-TLE2 | LG Display | 18.5 | 1366×768 |
| LTM185AT02 | Samsung | 18.5 | 1366×768 |
| M185BGE-L22 | Innolux | 18.5 | 1366×768 |
| M185XW01 V2 | AUO | 18.5 | 1366×768 |
| M185XW01 V3 | AUO | 18.5 | 1366×768 |
| HV320WHB-N00 | BOE | 31.5 | 1366×768 |
| LC370WUE-SBB2 | LG Display | 37 | 1920×1080 |
| LC650DUF-FGA2 | LG Display | 65 | 1920×1080 |
| LSC480FJ01 | Samsung | 48 | 3840×2160 |
| LTA320AP33 | Samsung | 31.5 | 1366×768 |
| T370HW03 VD | AUO | 37 | 1920×1080 |
| T420HW08 V0 CELL | AUO | 42 | 1920×1080 |
| T460HW07 V5 | AUO | 46 | 1920×1080 |
| V315B1-L01 | Innolux | 31.5 | 1366×768 |
| V420H2-LS2 Rev.C7 | Innolux | 42 | 1920×1080 |
