| Varenummer | LC390TU1A |
| Mærke | PANDA |
| Størrelse | 39 |
| Ansøgning | LCTV |
| Løsning | 1366×768 |
| Sammensætning | CELL |
| Lysstyrke | 0 |
| CR | 5000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | No B/L |
| Interface | LVDS |
| panel mærke | PANDA |
| panel model | LC390TU1A |
| paneltype | a-Si TFT-LCD , CELL |
| panelstørrelse | 39 inch |
| løsning | 1366(RGB)×768 , WXGA |
| visningstilstand | UV2A, Normally Black, Transmissive |
| aktivt område | 856.482×472.128 mm |
| omrids | 869.7×487.3 mm |
| overflade | Antiglare, Hard coating (3H) |
| glas dybde | 0.50+0.50 mm |
| transmissivitet | 7.8% (Typ.)(with Polarizer) |
| kontrastforhold | 5000:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193172% |
| responstid | 7 (Typ.)(G to G) |
| synsvinkel | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| signal interface | LVDS (1 ch, 8-bit), 30 pins |
| indgangsspænding | 12.0V (Typ.) |
| Ansøgning | LCTV |
| LC390TA2A | PANDA | 39 | 1366×768 |
| LC390TU1A | PANDA | 39 | 1366×768 |
| T390HVD03.1 CELL | AUO | 39 | 1920×1080 |
| T390HVF01.0 | AUO | 39 | 1920×1080 |
| T390HVN02.2 | AUO | 39 | 1920×1080 |
| V390DK1-LS1 | Innolux | 39 | 3840×2160 |
| V390HJ1-LE1 | Innolux | 39 | 1920×1080 |
| V390HJ1-LE6 | Innolux | 39 | 1920×1080 |
| V390HK1-LS6 | Innolux | 39 | 1920×1080 |
| LC216EXN-SDA1 | LG Display | 21.6 | 1366×768 |
| LC370EUS-SDS1 | LG Display | 36.5 | 1920×1080 |
| LC420DUK-SGK2 | LG Display | 42 | 1920×1080 |
| LSC550FN05 | Samsung | 55 | 3840×2160 |
| T260XW02 VL | AUO | 26.0 | 1366×768 |
| T400HW04 V1 | AUO | 40 | 1920×1080 |
| T460HB01 V0 | AUO | 46 | 1920×1080 |
| T460HW03 VF | AUO | 46 | 1920×1080 |
| V400HJ6-PE1 | Innolux | 40 | 1920×1080 |
| V580HJ1-LE6 | Innolux | 58 | 1920×1080 |
