| Varenummer | LC550DUS-SCM3 |
| Mærke | LG Display |
| Størrelse | 55 |
| Ansøgning | LCTV |
| Løsning | 1920×1080 |
| Sammensætning | LCM |
| Lysstyrke | 500 |
| CR | 1300:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | Mini LVDS |
| panel mærke | LG Display |
| panel model | LC550DUS-SCM3 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 55 inch |
| løsning | 1920(RGB)×1080 , FHD |
| visningstilstand | S-IPS, Normally Black, Transmissive |
| aktivt område | 1209.6×680.4 mm |
| omrids | 1286×745 mm |
| overflade | Hard coating (3H), Reflection 2.0% (Typ.) |
| lysstyrke | 500 cd/m² (Typ.) |
| kontrastforhold | 1300:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193172% |
| responstid | 6/6 (Typ.)(Tr/Td) |
| synsvinkel | 89/89/89/89 (Min.)(CR≥10)(L/R/U/D) |
| frekvens | 240Hz |
| lampe type | WLEDWithout Driver |
| signal interface | Mini LVDS, 160 pins |
| indgangsspænding | 3.3/16.2V (Typ.)(VCC/VDD) |
| Ansøgning | LCTV |
