| Varenummer | LC550EUB-SCA1 |
| Mærke | LG Display |
| Størrelse | 55 |
| Ansøgning | LCTV |
| Løsning | 1920×1080 |
| Sammensætning | LCM |
| Lysstyrke | 450 |
| CR | 1400:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | Mini LVDS |
| panel mærke | LG Display |
| panel model | LC550EUB-SCA1 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 55 inch |
| løsning | 1920(RGB)×1080 , FHD |
| visningstilstand | IPS, Normally Black, Transmissive |
| aktivt område | 1209.6×680.4 mm |
| omrids | 1261.6×732.4 mm |
| overflade | Antiglare (Haze 10%), Hard coating (3H) |
| lysstyrke | 450 cd/m² (Typ.) |
| kontrastforhold | 1400:1 (Typ.) |
| vise farver | 16.7M (8-bit) |
| responstid | 8/10 (Typ.)(Tr/Td) |
| synsvinkel | 89/89/89/89 (Min.)(CR≥10)(L/R/U/D) |
| frekvens | 120Hz+120Hz |
| lampe type | WLEDEmbedded (LED Driver) |
| signal interface | Mini LVDS, 120 pins |
| indgangsspænding | 3.3/16.3/28/-5.3V (Typ.)(VCC/VDD/VGH/VGL) |
| Ansøgning | LCTV |
