| Varenummer | LM140LF2L |
| Mærke | PANDA |
| Størrelse | 14.0 |
| Ansøgning | Laptop |
| Løsning | 1920×1080 |
| Sammensætning | Oxide TFT-LCD , LCM |
| Lysstyrke | |
| CR | 1000:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | eDP |
| mærke | PANDA |
| diagonal størrelse | 14.0 inch |
| pixel format | 1920(RGB)×1080 [FHD] 157PPI |
| aktivt område | 309.312(H)×173.988(V) mm |
| bezel område | - |
| luminans | 220 cd/m² (Typ.) |
| visningsretning | Symmetry |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10) |
| støtte farve | 262K 45% NTSC |
| form stil | Slim (PCBA Flat, T≤3.2mm) |
| billedhastighed | 60Hz |
| interface type | eDP (2 Lanes) , eDP1.2 , HBR1 (2.7G/lane) , 30 pins Connector |
| Strømforsyning | 3.3V (Typ.) |
| miljø | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| model | LM140LF2L (NCP002B) |
| type | Oxide TFT-LCD , LCM |
| konfiguration | RGB Vertical Stripe |
| omrids dim. | 315.81(H)×197.57(V) ×3(D) mm |
| behandling | Antiglare (Haze 25%) |
| kontrastforhold | 1000:1 (Typ.) (TM) |
| responstid | 25 (Typ.)(Tr+Td) |
| driftstilstand | FFS, Normally Black, Transmissive |
| lyskilde | WLED , 15K hours , With LED Driver |
| designet til | Laptop |
| berøringspanel | Without |
| B140XW02 V1 | AUO | 14.0 | 1366×768 |
| LP140WF1-SPJ1 | LG Display | 14.0 | 1920×1080 |
| LP140WF1-SPU1 | LG Display | 14.0 | 1920×1080 |
| LP140WF6-SPB3 | LG Display | 14.0 | 1920×1080 |
| LP140WH2-TLE3 | LG Display | 14.0 | 1366×768 |
| LP140WH2-TLN1 | LG Display | 14.0 | 1366×768 |
| LTN140AT20-701 | Samsung | 14.0 | 1366×768 |
| LTN140KT04-201 | Samsung | 14.0 | 1600×900 |
| M140NWR2 R0 | IVO | 14.0 | 1366×768 |
| N140B6-L06 | Innolux | 14.0 | 1366×768 |
