| Varenummer | LM170E03-TLJ2 |
| Mærke | LG Display |
| Størrelse | 17.0 |
| Ansøgning | DMPC |
| Løsning | 1280×1024 |
| Sammensætning | LCM |
| Lysstyrke | |
| CR | |
| Farver | 16.7M |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | LG Display |
| panel model | LM170E03-TLJ2 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 17.0 inch |
| løsning | 1280(RGB)×1024 , SXGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 337.92×270.336 mm |
| overflade | |
| lysstyrke | |
| kontrastforhold | |
| vise farver | 16.7M (6-bit + Hi-FRC) |
| responstid | |
| synsvinkel | |
| frekvens | 60Hz |
| lampe type | 2 pcsCCFL |
| signal interface | LVDS (2 ch, 8-bit) |
| Ansøgning | DMPC |
