| Varenummer | LM171WX3-TLC1 |
| Mærke | LG Display |
| Størrelse | 17.1 |
| Ansøgning | DMPC |
| Løsning | 1440×900 |
| Sammensætning | LCM |
| Lysstyrke | 250 |
| CR | 800:1 |
| Farver | 16.7M |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | LG.Philips LCD |
| panel model | LM171WX3-TLC1 4 Compatible model |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 17.1 inch |
| løsning | 1440(RGB)×900 , WXGA+ |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 367.2×229.5 mm |
| omrids | 389.2×254.5×12 mm |
| overflade | Antiglare (Haze 12%), Hard coating (3H) |
| lysstyrke | 250 cd/m² (Typ.) |
| kontrastforhold | 800:1 (Typ.) |
| vise farver | 16.7M (6-bit + Hi-FRC), CIE193160% |
| responstid | 2/6 (Typ.)(Tr/Td) |
| synsvinkel | 85/85/65/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 2 pcsCCFLWithout Driver |
| signal interface | LVDS (2 ch, 8-bit), 30 pins |
| indgangsspænding | 5.0V (Typ.) |
| Ansøgning | DMPC |
| LM230WF5-TLC1 | LG Display | 23.0 | 1920×1080 |
| LM300WQ5-SDA1 | LG Display | 30.0 | 2560×1600 |
| LTM170E8-L02 | Samsung | 17.0 | 1280×1024 |
| LTM190E4-L03 | Samsung | 19.0 | 1280×1024 |
| M190A1-L01 | Innolux | 19.0 | 1440×900 |
| M215HW01 V0 | AUO | 21.5 | 1920×1080 |
| M236H1-P01 | Innolux | 23.6 | 1920×1080 |
| M240HW02 V1 | AUO | 24.0 | 1920×1080 |
| M240UP01 V0 | AUO | 24.0 | 1920×1200 |
| P236MWF1 R0 | IVO | 23.6 | 1920×1080 |
