| Varenummer | LM250WW1-SSA1 |
| Mærke | LG Display |
| Størrelse | 25.0 |
| Ansøgning | DMPC |
| Løsning | 2560×1080 |
| Sammensætning | LCM |
| Lysstyrke | 250 |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | LG Display |
| panel model | LM250WW1-SSA1 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 25.0 inch |
| løsning | 2560(RGB)×1080 , CSHD |
| visningstilstand | AH-IPS, Normally Black, Transmissive |
| aktivt område | 585.216×246.888 mm |
| omrids | 602.2×271.2×16.5 mm |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | 250 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 16.7M (8-bit), sRGB99% |
| responstid | 14 (Typ.)(G to G) |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 15S4PWLEDWithout Driver |
| signal interface | LVDS (4 ch, 8-bit), 92 pins |
| indgangsspænding | 10.0V (Typ.) |
| Ansøgning | DMPC |
