| Varenummer | LM270WQ1-SDDA |
| Mærke | LG Display |
| Størrelse | 27.0 |
| Ansøgning | DMPC |
| Løsning | 2560×1440 |
| Sammensætning | LCM |
| Lysstyrke | 380 |
| CR | 1000:1 |
| Farver | 1.07B |
| Baggrundsbelysning | WLED |
| Interface | eDP |
| panel mærke | LG Display |
| panel model | LM270WQ1-SDDA |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 27.0 inch |
| løsning | 2560(RGB)×1440 , Quad-HD |
| visningstilstand | H-IPS, Normally Black, Transmissive |
| aktivt område | 596.736×335.664 mm |
| omrids | 630×376.13×22.3 mm |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | 380 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 1.07B (10-bit), sRGB |
| responstid | 6.5/7.5 (Typ.)(Tr/Td) |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDWithout Driver |
| signal interface | eDP (4 Lanes), 30 pins |
| indgangsspænding | 12.0V (Typ.) |
| Ansøgning | DMPC |
