| Varenummer | LP156UD1-SPA2 |
| Mærke | LG Display |
| Størrelse | 15.6 |
| Ansøgning | NBPC |
| Løsning | 3840×2160 |
| Sammensætning | LCM |
| Lysstyrke | 300 |
| CR | 800:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | eDP |
| panel mærke | LG Display |
| panel model | LP156UD1-SPA2 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 15.6 inch |
| løsning | 3840RG(BW)×2160 , UHD |
| visningstilstand | IPS, Normally Black, Transmissive |
| aktivt område | 344.448×193.752 mm |
| omrids | 359.5×223.8×2.9 mm |
| form stil | Slim (PCBA Flat, Depth ≤3.2mm) |
| overflade | Glare (Haze 0%), Hard coating (3H) |
| lysstyrke | 300 cd/m² (Typ.) |
| kontrastforhold | 800:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193172% |
| responstid | 25 (Typ.)(Tr+Td) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDEmbedded (LED Driver) |
| signal interface | eDP (4 Lanes), 40 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | NBPC |
| B156XW02 V2 HW4A | AUO | 15.6 | 1366×768 |
| CLAA156WA15A | CPT | 15.6 | 1366×768 |
| LP156UD1-SPA2 | LG Display | 15.6 | 3840×2160 |
| LP156WH3-TLSA | LG Display | 15.6 | 1366×768 |
| LP156WHB-TLA1 | LG Display | 15.6 | 1366×768 |
| LTN156AT02 | Samsung | 15.6 | 1366×768 |
| LTN156AT05-601 | Samsung | 15.6 | 1366×768 |
| LTN156AT29-W02 | Samsung | 15.6 | 1366×768 |
| N156BGE-E21 | Innolux | 15.6 | 1366×768 |
| N156O6-L02 | Innolux | 15.6 | 1600×900 |
| B133HAN02.0 | AUO | 13.3 | 1920×1080 |
| B170PW03 V3 | AUO | 17.0 | 1440×900 |
| CLAA156WA01A | CPT | 15.6 | 1366×768 |
| LP133WX3-TLA1 | LG Display | 13.3 | 1280×800 |
| LP141WX5-TLN1 | LG Display | 14.1 | 1280×800 |
| LTM10C313S | TOSHIBA | 10.4 | 1024×768 |
| LTM10C327F | TOSHIBA | 10.4 | 1024×768 |
| LTN133AT23-001 | Samsung | 13.3 | 1366×768 |
| LTN133AT27-102 | Samsung | 13.3 | 1366×768 |
| N133HSE-EB2 | Innolux | 13.3 | 1920×1080 |
