| Varenummer | LQ108M1JW02 |
| Mærke | SHARP |
| Størrelse | 10.8 |
| Ansøgning | NBPC |
| Løsning | 1920×1080 |
| Sammensætning | LCM |
| Lysstyrke | 400 |
| CR | 800:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | eDP |
| panel mærke | SHARP |
| panel model | LQ108M1JW02 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 10.8 inch |
| løsning | 1920(RGB)×1080 , FHD |
| visningstilstand | Normally Black, Transmissive |
| aktivt område | 239.04×134.46 mm |
| omrids | 250.2×149.1×2.5 mm |
| overflade | Antiglare (Haze 25%), Hard coating (3H) |
| lysstyrke | 400 cd/m² (Typ.) |
| kontrastforhold | 800:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193172% |
| responstid | 25 (Typ.)(Tr+Td) |
| synsvinkel | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 8S6PWLEDWithout Driver |
| signal interface | eDP (4 Lanes), 51 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | NBPC |
| LQ108M1JW01 | SHARP | 10.8 | 1920×1080 |
| LQ108M1JW02 | SHARP | 10.8 | 1920×1080 |
| B140XW01 V0 | AUO | 14.0 | 1366×768 |
| LP133WX2-TLA1 | LG Display | 13.3 | 1280×800 |
| LP140WD2-TLD2 | LG Display | 14.0 | 1600×900 |
| LQ164M1LA4A | SHARP | 16.4 | 1920×1080 |
| LSN133DL02-A02 | Samsung | 13.3 | 2560×1600 |
| LTN121AT02-001 | Samsung | 12.1 | 1280×800 |
| LTN154X3-L09-0 | Samsung | 15.4 | 1280×800 |
| LTN173KT01-D01 | Samsung | 17.3 | 1600×900 |
| N140O6-L02 | Innolux | 14.0 | 1600×900 |
| N141C3-L02 | Innolux | 14.1 | 1440×900 |
