| Varenummer | LSC400HM10 |
| Mærke | Samsung |
| Størrelse | 40 |
| Ansøgning | LCTV |
| Løsning | 1920×1080 |
| Sammensætning | CELL |
| Lysstyrke | 0 |
| CR | 4000:1 |
| Farver | 1.07B |
| Baggrundsbelysning | No B/L |
| Interface | LVDS |
| panel mærke | SAMSUNG |
| panel model | LSC400HM10 |
| paneltype | a-Si TFT-LCD , CELL |
| panelstørrelse | 40 inch |
| løsning | 1920(RGB)×1080 , FHD |
| visningstilstand | PVA, Normally Black, Transmissive |
| aktivt område | 885.6×498.15 mm |
| omrids | 899.6×513.95 mm |
| overflade | Antiglare |
| glas dybde | 0.70+0.70 mm |
| transmissivitet | 5.6% (Typ.)(with Polarizer) |
| kontrastforhold | 4000:1 (Typ.) |
| vise farver | 1.07B (8-bit + Dithering), CIE193168% |
| responstid | 8 (Typ.)(G to G) |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| signal interface | LVDS (2 ch, 10-bit), 51 pins |
| indgangsspænding | 12.0V (Typ.) |
| Ansøgning | LCTV |
