| Varenummer | LTA320AP18 |
| Mærke | Samsung |
| Størrelse | 31.5 |
| Ansøgning | LCTV |
| Løsning | 1366×768 |
| Sammensætning | LCM |
| Lysstyrke | 430 |
| CR | 4000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | SAMSUNG |
| panel model | LTA320AP18 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 31.5 inch |
| løsning | 1366(RGB)×768 , WXGA |
| visningstilstand | PVA, Normally Black, Transmissive |
| aktivt område | 697.685×392.256 mm |
| omrids | 741.4×435.8 mm |
| overflade | Antiglare (Haze 7%), Hard coating (3H) |
| lysstyrke | 430 cd/m² (Typ.) |
| kontrastforhold | 4000:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193172% |
| responstid | 20 (Typ.)(G to G) |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDEmbedded (LED Driver) |
| signal interface | LVDS (1 ch, 8-bit), 30 pins |
| indgangsspænding | 12.0V (Typ.) |
| Ansøgning | LCTV |
| LTA320AN01-C | Samsung | 31.5 | 1366×768 |
| LTA320AN01-D | Samsung | 31.5 | 1366×768 |
| LTA320AP09 | Samsung | 31.5 | 1366×768 |
| LTA320AP18 | Samsung | 31.5 | 1366×768 |
| LTA320AP29-W | Samsung | 31.5 | 1366×768 |
| LTA320AP33 | Samsung | 31.5 | 1366×768 |
| LTA320HA02 | Samsung | 31.5 | 1920×1080 |
| LTA320HN04-W | Samsung | 31.5 | 1920×1080 |
| LTA320WT-L08 | Samsung | 31.5 | 1366×768 |
| LTA320WT-L16 | Samsung | 31.5 | 1366×768 |
| LC420EUD-FFF1 | LG Display | 42 | 1920×1080 |
| LC420EUF-SCR1 | LG Display | 42 | 1920×1080 |
| LC420EUN-SEM1 | LG Display | 42 | 1920×1080 |
| LC600EUD-FEF2 | LG Display | 60 | 1920×1080 |
| LTA400HM02 | Samsung | 40 | 1920×1080 |
| T260XW01 V5 | AUO | 26.0 | 1280×768 |
| T420HW07 V4 | AUO | 42 | 1920×1080 |
| T460HW04 V5 | AUO | 46 | 1920×1080 |
| V320B1-L01 | Innolux | 32.0 | 1366×768 |
| V580DK2-KS1 Rev.C8 | Innolux | 58 | 3840×2160 |
