| Varenummer | LTA550HQ23-W |
| Mærke | Samsung |
| Størrelse | 55 |
| Ansøgning | LCTV |
| Løsning | 1920×1080 |
| Sammensætning | LCM |
| Lysstyrke | 360 |
| CR | 4000:1 |
| Farver | 16.7M/1.07B |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | SAMSUNG |
| panel model | LTA550HQ23-W |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 55 inch |
| løsning | 1920(RGB)×1080 , FHD |
| visningstilstand | SVA, Normally Black, Transmissive |
| aktivt område | 1209.6×680.4 mm |
| omrids | 1229.4×704.2 mm |
| overflade | Antiglare (Haze 2.3%), Hard coating (2H) |
| lysstyrke | 360 cd/m² (Typ.) |
| kontrastforhold | 4000:1 (Typ.) |
| vise farver | 16.7M/1.07B (8-bit / 8-bit + Dithering), CIE193170% |
| responstid | 8 (Typ.)(G to G) |
| synsvinkel | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDEmbedded (LED Driver) |
| signal interface | LVDS (2 ch, 8/10-bit) |
| indgangsspænding | 12.0V (Typ.) |
| Ansøgning | LCTV |
