| Varenummer | LTM200KT10 |
| Mærke | Samsung |
| Størrelse | 20.0 |
| Ansøgning | DMPC |
| Løsning | 1600×900 |
| Sammensætning | LCM |
| Lysstyrke | 250 |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | SAMSUNG |
| panel model | LTM200KT10 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 20.0 inch |
| løsning | 1600(RGB)×900 , HD+ |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 442.8×249.075 mm |
| omrids | 462.8×272×10.3 mm |
| overflade | Antiglare (Haze 25%), Hard coating (3H) |
| lysstyrke | 250 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193172% |
| responstid | 5 (Typ.)(Tr+Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 8S3PWLEDWithout Driver |
| signal interface | LVDS (2 ch, 8-bit), 30 pins |
| indgangsspænding | 5.0V (Typ.) |
| Ansøgning | DMPC |
| LTM200KP01 | Samsung | 20.0 | 1600×900 |
| LTM200KT01 | Samsung | 20.0 | 1600×900 |
| LTM200KT03 | Samsung | 20.0 | 1600×900 |
| LTM200KT05 | Samsung | 20.0 | 1600×900 |
| LTM200KT07 | Samsung | 20.0 | 1600×900 |
| LTM200KT08-V | Samsung | 20.0 | 1600×900 |
| LTM200KT10 | Samsung | 20.0 | 1600×900 |
| LTM200KT12 | Samsung | 20.0 | 1600×900 |
| LTM201M1-L01 | Samsung | 20.1 | 1680×1050 |
| LTM201M2-L02 | Samsung | 20.1 | 1680×1050 |
| CLAA185WA02 | CPT | 18.5 | 1366×768 |
| LM171W02-TLB2 | LG Display | 17.1 | 1440×900 |
| LM190E08-TLJ8 | LG Display | 19.0 | 1280×1024 |
| LM220WE1-TLE2 | LG Display | 22.0 | 1680×1050 |
| LM240WU7-SLB3 | LG Display | 24.0 | 1920×1200 |
| LTM170EI-A01 | Samsung | 17.0 | 1280×1024 |
| LTM170ET01 | Samsung | 17.0 | 1280×1024 |
| LTM270HT03 | Samsung | 27.0 | 1920×1080 |
| M215HGE-L21 | Innolux | 21.5 | 1920×1080 |
| M236HGK-L30 | Innolux | 23.6 | 1920×1080 |
