| Varenummer | LTN145AT01-H01 |
| Mærke | Samsung |
| Størrelse | 14.5 |
| Ansøgning | NBPC |
| Løsning | 1366×768 |
| Sammensætning | LCM |
| Lysstyrke | 220 |
| CR | 500:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | SAMSUNG |
| panel model | LTN145AT01-H01 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 14.5 inch |
| løsning | 1366(RGB)×768 , WXGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 321.693×180.864 mm |
| omrids | 336.8×196.9×5.3 mm |
| form stil | Wedge (PCBA Bent, Depth ≥5.2mm) |
| overflade | Glare (Haze 0%), Hard coating (3H) |
| lysstyrke | 220 cd/m² (Typ.) |
| kontrastforhold | 500:1 (Typ.) |
| vise farver | 262K (6-bit), CIE193160% |
| responstid | 8 (Typ.)(G to G) |
| synsvinkel | 45/45/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDEmbedded (LED Driver) |
| signal interface | LVDS (1 ch, 6-bit), 40 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | NBPC |
| LP145WH1-TLA1 | LG Display | 14.5 | 1366×768 |
| LTN145AT01-H01 | Samsung | 14.5 | 1366×768 |
| BT140GW02 V.9 | Innolux | 14.0 | 1366×768 |
| HB140WH1-504 | BOE | 14.0 | 1366×768 |
| LP154WE2-TLA7 | LG Display | 15.4 | 1680×1050 |
| LP156WH1-TLC1 | LG Display | 15.6 | 1366×768 |
| LP156WH2-TLG1 | LG Display | 15.6 | 1366×768 |
| LP156WHB-TPD1 | LG Display | 15.6 | 1366×768 |
| LTN133AT23-B01 | Samsung | 13.3 | 1366×768 |
| LTN156AT17-D01 | Samsung | 15.6 | 1366×768 |
| N154I4-L04 | Innolux | 15.4 | 1280×800 |
| N156BGE-EA1 | Innolux | 15.6 | 1366×768 |
