| Varenummer | LTN156AT20-P01 |
| Mærke | Samsung |
| Størrelse | 15.6 |
| Ansøgning | NBPC |
| Løsning | 1366×768 |
| Sammensætning | LCM |
| Lysstyrke | 200 |
| CR | |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | |
| panel mærke | SAMSUNG |
| panel model | LTN156AT20-P01 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 15.6 inch |
| løsning | 1366(RGB)×768 , WXGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 344.232×193.536 mm |
| form stil | Flat (PCBA Flat, Depth 3.4~4.0mm) |
| overflade | |
| lysstyrke | 200 cd/m² (Typ.) |
| kontrastforhold | |
| vise farver | 262K (6-bit) |
| responstid | |
| synsvinkel | |
| frekvens | 60Hz |
| lampe type | WLEDEmbedded (LED Driver) |
| Ansøgning | NBPC |
| LTN156AT01-H01 | Samsung | 15.6 | 1366×768 |
| LTN156AT02-A04 | Samsung | 15.6 | 1366×768 |
| LTN156AT02-A11 | Samsung | 15.6 | 1366×768 |
| LTN156AT02-D03 | Samsung | 15.6 | 1366×768 |
| LTN156AT02-D04 | Samsung | 15.6 | 1366×768 |
| LTN156AT06-001 | Samsung | 15.6 | 1366×768 |
| LTN156AT24-P01 | Samsung | 15.6 | 1366×768 |
| LTN156AT29-L01 | Samsung | 15.6 | 1366×768 |
| LTN156AT34-D01 | Samsung | 15.6 | 1366×768 |
| LTN156AT36-W01 | Samsung | 15.6 | 1366×768 |
| B154EW09 V1 | AUO | 15.4 | 1280×800 |
| LP104V2 | LG Display | 10.4 | 640×480 |
| LP156WD1-TLD5 | LG Display | 15.6 | 1600×900 |
| LP156WF4-SPU1 | LG Display | 15.6 | 1920×1080 |
| LP156WH2-TLG1 | LG Display | 15.6 | 1366×768 |
| LP173WD1-TLG2 | LG Display | 17.3 | 1600×900 |
| N140BGE-L21 | Innolux | 14.0 | 1366×768 |
| N156BGE-EA1 | Innolux | 15.6 | 1366×768 |
| N156O6-L04 | Innolux | 15.6 | 1600×900 |
| N164HGE-L12 | Innolux | 16.4 | 1920×1080 |
