| Varenummer | NT140WHM-N45 |
| Mærke | BOE |
| Størrelse | 14.0 |
| Ansøgning | Laptop |
| Løsning | 1366×768 |
| Sammensætning | LCM, a-Si TFT-LCD |
| Lysstyrke | |
| CR | 500:1 |
| Farver | 262K |
| Baggrundsbelysning | 10S4P |
| Interface | eDP |
| fabrikant | BOE |
| modelnavn | NT140WHM-N45 (BOE07E8) |
| skærmstørrelse | 14.0 inch |
| skærmtype | LCM, a-Si TFT-LCD |
| pixel antal | 1366(RGB)×768 (WXGA) 112PPI |
| arrangement | RGB Vertical Stripe |
| aktivt område (mm) | 309.112 × 173.791 (H×V) |
| omrids (mm) | 315.81 × 186.09 × 3 (H×V×D) |
| rammeareal (mm) | - |
| behandling | Antiglare, Hard coating (3H) |
| luminans | 220 cd/m² (Typ.) |
| kontrastforhold | 500 : 1 (Typ.) (TM) |
| synsvinkel | 45/45/20/40 (Typ.)(CR≥10) |
| respons | 12 (Typ.)(Tr+Td) ms |
| god udsigt kl | 6 o'clock |
| arbejdstilstand | TN, Normally White, Transmissive |
| farvedybde | 262K 45% NTSC |
| baggrundsbelysning | 10S4P WLED , 15K hours , With LED Driver |
| konturform | Slim (PCBA Bent, T≤3.0mm) |
| anvendes til | Laptop |
| opdateringshastighed | 60Hz |
| berøringsskærm | Without |
| signaltype | eDP (1 Lane) , eDP1.2 , HBR1 (2.7G/lane) , Connector 30 pins |
| spændingsforsyning | 3.3V (Typ.) |
| max. vurderinger | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| B140XW02 V1 | AUO | 14.0 | 1366×768 |
| BT140GW02 V.2 | Innolux | 14.0 | 1366×768 |
| HSD140PHW2-A00 | HannStar | 14.0 | 1366×768 |
| LP140WH2-TLL1 | LG Display | 14.0 | 1366×768 |
| LP140WH6-TLB1 | LG Display | 14.0 | 1366×768 |
| LTN140AT07-306 | Samsung | 14.0 | 1366×768 |
| LTN140AT07-401 | Samsung | 14.0 | 1366×768 |
| LTN140AT20-W05 | Samsung | 14.0 | 1366×768 |
| LTN140AT21-B01 | Samsung | 14.0 | 1366×768 |
| NT140WHM-N31 | BOE | 14.0 | 1366×768 |
