| Varenummer | P460HW02 V0 |
| Mærke | AUO |
| Størrelse | 46 |
| Ansøgning | PID |
| Løsning | 1920×1080 |
| Sammensætning | LCM |
| Lysstyrke | 1500 |
| CR | 4000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | AUO |
| panel model | P460HW02 V0 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 46 inch |
| løsning | 1920(RGB)×1080 , FHD |
| visningstilstand | AMVA3, Normally Black, Transmissive |
| aktivt område | 1018.08×572.67 mm |
| omrids | 1048.4×605 mm |
| overflade | Antiglare (Haze 11%), Hard coating (3H) |
| lysstyrke | 1500 cd/m² (Typ.) |
| kontrastforhold | 4000:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193172% |
| responstid | 8 (Typ.)(G to G) |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | CCFLEmbedded (Inverter) |
| signal interface | LVDS (2 ch, 8-bit), 51 pins |
| indgangsspænding | 12.0V (Typ.) |
| Ansøgning | PID |
| LD320WUD-SBA1 | LG Display | 31.5 | 1920×1080 |
| LD420WUB-SCA1 | LG Display | 42 | 1920×1080 |
| LD470EUD-SDA1 | LG Display | 47 | 1920×1080 |
| LD470WUB-SCA1 | LG Display | 47 | 1920×1080 |
| LTI370LN03 | Samsung | 37 | 1920×540 |
| LTI460HN03 | Samsung | 46 | 1920×1080 |
| P270HVN01.0 | AUO | 27.0 | 1920×1080 |
| P460HW02 V0 | AUO | 46 | 1920×1080 |
| P546HW01 V0 | AUO | 55 | 1920×1080 |
| P650HVN01.0 | AUO | 65 | 1920×1080 |
