| Varenummer | RGS10128032WR006 |
| Mærke | RiTdisplay |
| Størrelse | 1.0 |
| Ansøgning | IA |
| Løsning | 128×32 |
| Sammensætning | OLED |
| Lysstyrke | 120 |
| CR | 2000:1 |
| Farver | Mono(White) |
| Baggrundsbelysning | self |
| Interface | CPU/SPI/I²C |
| panel mærke | RiTdisplay |
| panel model | RGS10128032WR006 |
| paneltype | PM-OLED , OLED |
| panelstørrelse | 1.0 inch |
| løsning | 128×32 |
| aktivt område | 25.58×6.38 mm |
| omrids | 29.8×15.4×1.31 mm |
| overflade | Antiglare |
| lysstyrke | 120 cd/m² (Typ.) |
| kontrastforhold | 2000 : 1 (Min.) |
| vise farver | Mono(White) (1-bit) |
| synsvinkel | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| frekvens | 105Hz |
| driver ic | COG Built-in LD7032 |
| signal interface | 8-bit 6800/8080 parallel, SPI, I²C, 28 pins |
| indgangsspænding | 12/(1.8/2.8)V (Typ.)(VCC/VDD) |
