| Varenummer | RX366HDL-C07 |
| Mærke | ROGIN |
| Størrelse | 36.6 |
| Ansøgning | PID |
| Løsning | 1920×290 |
| Sammensætning | LCM |
| Lysstyrke | 700 |
| CR | 3000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | ROGIN |
| panel model | RX366HDL-C07 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 36.6 inch(1/4 cut of 42") |
| løsning | 1920(RGB)×290 |
| visningstilstand | Normally Black, Transmissive |
| aktivt område | 919.296×138.852 mm |
| omrids | 960×180.85×29 mm |
| overflade | Antiglare (Haze 1%), Hard coating (3H) |
| lysstyrke | 700 cd/m² (Typ.) |
| kontrastforhold | 3000:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193170% |
| responstid | 6.5 (Typ.)(G to G) |
| synsvinkel | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDEmbedded (LED Driver) |
| signal interface | LVDS (2 ch, 8-bit), 51 pins |
| indgangsspænding | 12.0V (Typ.) |
| Ansøgning | PID |
