| Varenummer | S50HW-YB06 |
| Mærke | Samsung |
| Størrelse | 50 |
| Ansøgning | LCTV |
| Løsning | 1365×768 |
| Sammensætning | PDP |
| Lysstyrke | 630 |
| CR | 5000:1 |
| Farver | 1.07B |
| Baggrundsbelysning | self |
| Interface | LVDS |
| panel mærke | SAMSUNG SDI |
| panel model | S50HW-YB06 |
| paneltype | PDP , PDP |
| panelstørrelse | 50 inch |
| løsning | 1365(RGB)×768 , WXGA |
| aktivt område | 1105.65×622.08 mm |
| omrids | 1175.4×688 mm |
| overflade | |
| lysstyrke | 630 cd/m² (Typ.) |
| kontrastforhold | 5000 : 1 (Typ.) |
| vise farver | 1.07B (10-bit) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| signal interface | LVDS (1 ch, 10-bit) + SPI, 30 pins |
| rohs: | |
| Ansøgning | LCTV |
