| Varenummer | TCG121XGLPBPNN-AN40-S |
| Mærke | Kyocera |
| Størrelse | 12.1 |
| Ansøgning | Industrial Outdoor H |
| Løsning | 1024×768 |
| Sammensætning | a-Si TFT-LCD, LCM |
| Lysstyrke | |
| CR | 600:1 |
| Farver | 262K/16.2M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | Kyocera |
| panel model | TCG121XGLPBPNN-AN40-S |
| panelstørrelse | 12.1" |
| paneltype | a-Si TFT-LCD, LCM |
| løsning | 1024(RGB)×768, XGA, 105PPI |
| pixel format | RGB Vertical Stripe |
| udstillingsområde | 245.76(W)×184.32(H) mm |
| bezel åbning | 249.0(W)×187.5(H) mm |
| konturstørrelse | 260.5(W)×203(H) ×10.9(D) mm |
| overflade | Antiglare |
| lysstyrke | 780 cd/m² (Typ.) |
| kontrastforhold | 600:1 (Typ.) (TM) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10) |
| visningstilstand | AWV, Normally Black, Transmissive |
| bedste udsigt på | Symmetry |
| responstid | 18/12 (Typ.)(Tr/Td) |
| vise farver | 262K/16.2M 51% NTSC |
| lampe type | WLED , 50K hours , With LED Driver |
| frekvens | 60Hz |
| berøringsskærm | Without |
| panelvægt | 555g |
| Ansøgning | Industrial Outdoor High Brightness |
| signal interface | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| indgangsspænding | 3.3V (Typ.) |
| miljø | Operating Temp.: -30 ~ 80 °C ; Storage Temp.: -30 ~ 80 °C |
| AA121SJ23 | Mitsubishi | 12.1 | 800×600 |
| B121EW09 V4 | AUO | 12.1 | 1280×800 |
| HV121WX5-113 | HYDIS | 12.1 | 1280×800 |
| LQ121S1DC71 | SHARP | 12.1 | 800×600 |
| LQ121X1LH73 | SHARP | 12.1 | 1024×768 |
| LTD121C32S | TOSHIBA | 12.1 | 800×600 |
| LTD121EA3P | TOSHIBA | 12.1 | 1024×768 |
| LTD121EXPD | TOSHIBA | 12.1 | 1280×800 |
| NL10276BC24-19D | NLT | 12.1 | 1024×768 |
| TCG121XGLPAPNN-AN20 | Kyocera | 12.1 | 1024×768 |
