| Varenummer | V236H1-LE4 |
| Mærke | Innolux |
| Størrelse | 23.6 |
| Ansøgning | LCTV |
| Løsning | 1920×1080 |
| Sammensætning | LCM |
| Lysstyrke | 280 |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | CHIMEI INNOLUX |
| panel model | V236H1-LE4 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 23.6 inch |
| løsning | 1920(RGB)×1080 , FHD |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 521.28×293.22 mm |
| omrids | 544.8×320.5 mm |
| overflade | Antiglare (Haze 25%) |
| lysstyrke | 280 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 16.7M (6-bit + Hi-FRC), CIE193172% |
| responstid | 1.5/3.5 (Typ.)(Tr/Td) |
| synsvinkel | 85/85/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 9S8PWLEDWithout Driver |
| signal interface | LVDS (2 ch, 8-bit), 30 pins |
| indgangsspænding | 5.0V (Typ.) |
| Ansøgning | LCTV |
| HM236WU3-100 | BOE | 23.6 | 1920×1080 |
| M236H1-L07 | Innolux | 23.6 | 1920×1080 |
| M236H1-P01 | Innolux | 23.6 | 1920×1080 |
| M236H3-LA3 | Innolux | 23.6 | 1920×1080 |
| M236HJJ-L31 | Innolux | 23.6 | 1920×1080 |
| M236HJK-L5B | Innolux | 23.6 | 1920×1080 |
| MV236WHM-N10 | BOE | 23.6 | 1366×768 |
| V236BJ1-PE2 | Innolux | 23.6 | 1366×768 |
| V236H1-L01 | Innolux | 23.6 | 1920×1080 |
| V236H1-LE4 | Innolux | 23.6 | 1920×1080 |
| LC150X02-TL01 | LG Display | 15.0 | 1024×768 |
| LC260WUN-SBA1 | LG Display | 26.0 | 1920×1080 |
| LC370WX5-SLA1 | LG Display | 37 | 1366×768 |
| LC420WUF-SBA1 | LG Display | 42 | 1920×1080 |
| LC470EUE-SEM1 | LG Display | 47 | 1920×1080 |
| LC550EGE-FHM1 | LG Display | 55 | 3840×2160 |
| T315HW04 VC | AUO | 31.5 | 1920×1080 |
| V260B1-L03 | Innolux | 26.0 | 1366×768 |
| V400DJ1-QS5 | Innolux | 40 | 3840×2160 |
| V580DK2-QS1 | Innolux | 58 | 3840×2160 |
