| Varenummer | V315B5-L01 |
| Mærke | Innolux |
| Størrelse | 31.5 |
| Ansøgning | LCTV |
| Løsning | 1366×768 |
| Sammensætning | LCM |
| Lysstyrke | 450 |
| CR | 3000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | CMO |
| panel model | V315B5-L01 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 31.5 inch |
| løsning | 1366(RGB)×768 , WXGA |
| visningstilstand | Super MVA, Normally Black, Transmissive |
| aktivt område | 697.685×392.256 mm |
| omrids | 760×450 mm |
| overflade | Antiglare (Haze 11%), Hard coating (3H) |
| lysstyrke | 450 cd/m² (Typ.) |
| kontrastforhold | 3000:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193172% |
| responstid | 8.5 (Typ.)(G to G) |
| synsvinkel | 88/88/88/88 (Typ.)(CR≥20)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 4 pcsCCFLWithout Driver |
| signal interface | LVDS (1 ch, 8-bit), 30 pins |
| indgangsspænding | 12.0V (Typ.) |
| Ansøgning | LCTV |
| V315B1-L01 | Innolux | 31.5 | 1366×768 |
| V315B3-L04 | Innolux | 31.5 | 1366×768 |
| V315B5-L01 | Innolux | 31.5 | 1366×768 |
| V315B5-L02 | Innolux | 31.5 | 1366×768 |
| V315B5-L03 | Innolux | 31.5 | 1366×768 |
| V315B5-LE2 | Innolux | 31.5 | 1366×768 |
| V315B5-LE3 | Innolux | 31.5 | 1366×768 |
| V315B5-P10 | Innolux | 31.5 | 1366×768 |
| V315B6-L02 | Innolux | 31.5 | 1366×768 |
| V315B6-L04 | Innolux | 31.5 | 1366×768 |
| LC370WUD-SBM2 | LG Display | 37 | 1920×1080 |
| LC370WUN-SCC1 | LG Display | 37 | 1920×1080 |
| LC420DUH-FGP1 | LG Display | 42 | 1920×1080 |
| LC420DUJ-SGE3 | LG Display | 42 | 1920×1080 |
| LC420EUN-FEF1 | LG Display | 42 | 1920×1080 |
| LC470EUN-PFF1 | LG Display | 47 | 1920×1080 |
| T240HW01 V0 | AUO | 24.0 | 1920×1080 |
| T320XW04 V3 CELL | AUO | 31.5 | 1366×768 |
| V236BJ1-P01 Rev.C3 | Innolux | 23.6 | 1366×768 |
| V420HK1-LS5 Rev.C7 | Innolux | 42 | 1920×1080 |
