| Varenummer | AA065VE11ADA11 |
| Mærke | Mitsubishi |
| Størrelse | 6.5 |
| Ansøgning | IA |
| Løsning | 640×480 |
| Sammensætning | LCM |
| Lysstyrke | 1000 |
| CR | 600:1 |
| Farver | 262K/16.7M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | Mitsubishi |
| panel model | AA065VE11ADA11 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 6.5 inch |
| løsning | 640(RGB)×480 , VGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 132.48×99.36 mm |
| omrids | 170.2×132.6×15.3 mm |
| overflade | Clear |
| lysstyrke | 1000 cd/m² (Typ.) |
| kontrastforhold | 600:1 (Typ.) |
| vise farver | 262K/16.7M (6-bit / 8-bit), CIE193140% |
| responstid | 6/19 (Typ.)(Tr/Td) |
| synsvinkel | 80/80/80/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 2 stringsWLEDWithout Driver |
| signal interface | LVDS (1 ch, 6/8-bit), 20 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | IA |
| AA065VE01 | Mitsubishi | 6.5 | 640×480 |
| AA065VE11ADA11 | Mitsubishi | 6.5 | 640×480 |
| G065VN01 V2 | AUO | 6.5 | 640×480 |
| L5F30818P03 | SONY | 6.5 | 800×480 |
| LQ065T5BR08 | SHARP | 6.5 | 400×240 |
| LQ065T5DG30 | SHARP | 6.5 | 400×240 |
| LQ065T9BR54U | SHARP | 6.5 | 400×240 |
| LQ065Y5DG01 | SHARP | 6.5 | 800×480 |
| LTA065A040F | TOSHIBA | 6.5 | 640×480 |
| NL6448BC20-30F | NLT | 6.5 | 640×480 |
| COM70T7M07ZLC | ORTUSTECH | 7.0 | 800×480 |
| G101STN01.2 | AUO | 10.1 | 1024×600 |
| G104VN01 V0 | AUO | 10.4 | 640×480 |
| KCG057QV1DB-G77 | Kyocera | 5.7 | 320×240 |
| LCBHBT161M | NAN YA | 5.7 | 320×240 |
| LQ150X1LW96 | SHARP | 15.0 | 1024×768 |
| LTB190E2-L01 | Samsung | 19.0 | 1280×1024 |
| PM070WL1 | E Ink | 7.0 | 800×480 |
| RGS32256064YH001 | RiTdisplay | 3.2 | 256×64 |
| TFD60W12-B | TOSHIBA | 6.0 | 320×234 |
