| Varenummer | RGS32256064YH001 |
| Mærke | RiTdisplay |
| Størrelse | 3.2 |
| Ansøgning | IA |
| Løsning | 256×64 |
| Sammensætning | OLED |
| Lysstyrke | 90 |
| CR | 2000:1 |
| Farver | Mono(Yellow) |
| Baggrundsbelysning | self |
| Interface | CPU/SPI |
| panel mærke | RiTdisplay |
| panel model | RGS32256064YH001 |
| paneltype | PM-OLED , OLED |
| panelstørrelse | 3.2 inch |
| løsning | 256×64 |
| aktivt område | 79.084×19.756 mm |
| omrids | 87.4×28.5×2.11 mm |
| overflade | Antiglare |
| lysstyrke | 90 cd/m² (Typ.) |
| kontrastforhold | 2000 : 1 (Min.) |
| vise farver | Mono(Yellow) (1-bit) |
| synsvinkel | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| frekvens | 105Hz |
| driver ic | COF Built-in SSD1332 |
| signal interface | 8-bit 6800/8080 parallel, 3/4-wire SPI, 34 pins |
| indgangsspænding | 14.5/2.8V (Typ.)(VCC/VCI) |
| Ansøgning | IA |
