| Varenummer | AA090MC01 |
| Mærke | Mitsubishi |
| Størrelse | 9.0 |
| Ansøgning | IA |
| Løsning | 800×480 |
| Sammensætning | LCM |
| Lysstyrke | 600 |
| CR | 600:1 |
| Farver | 262K/16.7M |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | Mitsubishi |
| panel model | AA090MC01 1 Compatible model |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 9.0 inch |
| løsning | 800(RGB)×480 , WVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 196.8×118.08 mm |
| omrids | 219×136.2×13.7 mm |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | 600 cd/m² (Typ.) |
| kontrastforhold | 600:1 (Typ.) |
| vise farver | 262K/16.7M (6-bit / 6-bit + Hi-FRC), CIE193140% |
| responstid | 4/12 (Typ.)(Tr/Td) |
| synsvinkel | 80/80/80/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 2 pcsCCFLWithout Driver |
| signal interface | LVDS (1 ch, 6/8-bit), 20 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | IA |
| A090PAN01.0 | AUO | 9.0 | 900×1440 |
| AA090AA01 | Mitsubishi | 9.0 | 960×540 |
| AA090MC01 | Mitsubishi | 9.0 | 800×480 |
| AA090ME01 | Mitsubishi | 9.0 | 800×480 |
| C090EAN01.1 | AUO | 9.0 | 1280×720 |
| DLC0900DIG-1 | Other | 9.0 | 800×480 |
| LTA090B400F | TOSHIBA | 9.0 | 800×480 |
| M090SWP1 R0 | IVO | 9.0 | 800×480 |
| NL6448BC28-01 | NLT | 9.0 | 640×480 |
| TX23D85VM0BAA | KOE | 9.0 | 1280×768 |
| AA084VC03 | Mitsubishi | 8.4 | 640×480 |
| EL160.80.50 ET CC | Lumineq | 3.5 | 160×80 |
| G057VGE-T01 | Innolux | 5.7 | 640×480 |
| G154IJE-L02 | Innolux | 15.4 | 1280×800 |
| HT150X02-101 | BOE | 15.0 | 1024×768 |
| LM-CK53-22NFR | SANYO | 9.4 | 640×480 |
| LT057AA34B00 | TOSHIBA | 5.7 | 320×240 |
| LTA057A340F | TOSHIBA | 5.7 | 320×240 |
| OEL9M0065-W-E | Other | 2.7 | 256×64 |
| TM150TCS02 | Tianma | 15.0 | 1024×768 |
