| Varenummer | G154IJE-L02 |
| Mærke | Innolux |
| Størrelse | 15.4 |
| Ansøgning | IA |
| Løsning | 1280×800 |
| Sammensætning | LCM |
| Lysstyrke | 400 |
| CR | 1000:1 |
| Farver | 262K/16.2M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | INNOLUX |
| panel model | G154IJE-L02 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 15.4 inch |
| løsning | 1280(RGB)×800 , WXGA |
| visningstilstand | MVA, Normally Black, Transmissive |
| aktivt område | 331.2×207 mm |
| omrids | 352×230×9.2 mm |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | 400 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 262K/16.2M (6-bit / 6-bit + FRC), CIE193145% |
| responstid | 15/10 (Typ.)(Tr/Td) |
| synsvinkel | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 9S5PWLEDEmbedded (LED Driver) |
| signal interface | LVDS (1 ch, 6/8-bit), 30 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | IA |
| B154EW01 V8 | AUO | 15.4 | 1280×800 |
| B154SW01 V1 | AUO | 15.4 | 1680×1050 |
| CLAA154WB04N | CPT | 15.4 | 1280×800 |
| G154I1-L01 | Innolux | 15.4 | 1280×800 |
| G154I1-LE1 | Innolux | 15.4 | 1280×800 |
| G154IJE-L02 | Innolux | 15.4 | 1280×800 |
| LP154W02-TL06 | LG Display | 15.4 | 1680×1050 |
| LP154WX7-TLA3 | LG Display | 15.4 | 1280×800 |
| LTN154BT05-D01 | Samsung | 15.4 | 1440×900 |
| LTN154X3-L0D-G | Samsung | 15.4 | 1280×800 |
| AA121XK04 | Mitsubishi | 12.1 | 1024×768 |
| COM65H6115DLC | ORTUSTECH | 6.5 | 640×480 |
| G070VTN01.0 | AUO | 7.0 | 800×480 |
| G150XGE-L05 | Innolux | 15.0 | 1024×768 |
| LM64P101R | SHARP | 7.2 | 640×480 |
| LQ150X1LX95 | SHARP | 15.0 | 1024×768 |
| LTM12C275A | TOSHIBA | 12.1 | 800×600 |
| SP10Q010 | KOE | 3.8 | 320×240 |
| TLX-1741-C3M | TOSHIBA | 5.4 | 240×128 |
| UG-2832TSWGG01 | WiseChip | 1.0 | 128×32 |
