| Varenummer | AM-1024768FCTMQW-T00H |
| Mærke | AMPIRE |
| Størrelse | 10.4 |
| Ansøgning | Industrial |
| Løsning | 1024×768 |
| Sammensætning | a-Si TFT-LCD, LCM |
| Lysstyrke | |
| CR | 1200:1 |
| Farver | 262K/16.2M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| mærke | AMPIRE |
| model | AM-1024768FCTMQW-T00H |
| diagonal størrelse | 10.4 inch |
| type | a-Si TFT-LCD, LCM |
| pixel format | 1024(RGB)×768 [XGA] 123PPI |
| konfiguration | RGB Vertical Stripe |
| aktivt område | 210.4(H)×157.8(V) mm |
| omrids dim. | 238.6(H)×175.8(V) mm |
| luminans | 280 cd/m² (Typ.) |
| kontrastforhold | 1200:1 (Typ.) (TM) |
| visningsretning | Symmetry |
| responstid | 14/11 (Typ.)(Tr/Td) |
| synsvinkel | 88/88/88/88 (Typ.)(CR≥10) |
| driftstilstand | Normally Black, Transmissive |
| støtte farve | 262K/16.2M 57% NTSC |
| lyskilde | WLED , 30K hours , With LED Driver |
| vægt | - |
| designet til | Industrial |
| billedhastighed | 60Hz |
| berøringspanel | PCAP |
| interface type | LVDS (1 ch, 6/8-bit) , 30 pins Connector |
| Strømforsyning | 3.3V (Typ.) |
| miljø | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
