| Varenummer | AM-1024768M2TMQW-T00H |
| Mærke | AMPIRE |
| Størrelse | 9.7 |
| Ansøgning | IA |
| Løsning | 1024×768 |
| Sammensætning | LCM |
| Lysstyrke | 425 |
| CR | |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | AMPIRE |
| panel model | AM-1024768M2TMQW-T00H |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 9.7 inch |
| løsning | 1024(RGB)×768 , WXGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 211.2×127.7 mm |
| omrids | 236×175 mm |
| overflade | |
| lysstyrke | 425 cd/m² (Typ.) |
| kontrastforhold | |
| vise farver | 262K (6-bit), CIE193147% |
| responstid | 25 (Typ.)(Tr+Td) |
| synsvinkel | 75/75/60/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 3S13PWLEDWithout Driver |
| signal interface | LVDS (1 ch, 6-bit), 30 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | IA |
