| Varenummer | AM-1280800J4TZQW-T00 |
| Mærke | AMPIRE |
| Størrelse | 10.1 |
| Ansøgning | Industrial |
| Løsning | 1280×800 |
| Sammensætning | a-Si TFT-LCD, LCM |
| Lysstyrke | |
| CR | 800:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| mærke | AMPIRE |
| model | AM-1280800J4TZQW-T00 |
| diagonal størrelse | 10.1 inch |
| type | a-Si TFT-LCD, LCM |
| pixel format | 1280(RGB)×800 [WXGA] 149PPI |
| konfiguration | RGB Vertical Stripe |
| aktivt område | 216.96(H)×135.6(V) mm |
| omrids dim. | 231(H)×150(V) ×8.8(D) mm |
| luminans | 300 cd/m² (Typ.) |
| kontrastforhold | 800:1 (Typ.) (TM) |
| visningsretning | Symmetry |
| responstid | 10/15 (Typ.)(Tr/Td) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10) |
| driftstilstand | Normally Black, Transmissive |
| støtte farve | 16.7M |
| lyskilde | WLED [3S11P] , 15K hours , With LED Driver |
| vægt | TBD |
| designet til | Industrial |
| billedhastighed | 60Hz |
| berøringspanel | PCAP |
| interface type | LVDS (1 ch, 8-bit) , 30 pins Connector |
| Strømforsyning | 3.3V (Typ.) |
| miljø | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
