| Varenummer | AM-320240N1TMQW-TW0H-A(R) |
| Mærke | AMPIRE |
| Størrelse | 5.7 |
| Ansøgning | Industrial |
| Løsning | 320×240 |
| Sammensætning | LCM, a-Si TFT-LCD |
| Lysstyrke | |
| CR | 350:1 |
| Farver | 65K/262K |
| Baggrundsbelysning | 3S7P |
| Interface | |
| fabrikant | AMPIRE |
| modelnavn | AM-320240N1TMQW-TW0H-A(R) |
| skærmstørrelse | 5.7 inch |
| skærmtype | LCM, a-Si TFT-LCD |
| pixel antal | 320(RGB)×240 (QVGA) 70PPI |
| arrangement | RGB Vertical Stripe |
| aktivt område (mm) | 115.2 × 86.4 (H×V) |
| omrids (mm) | 167 × 109 × 14.8 (H×V×D) |
| rammeareal (mm) | 118.2 × 89.4 (H×V) |
| behandling | - |
| luminans | 400 cd/m² (Typ.) |
| kontrastforhold | 350 : 1 (Min.) (TM) |
| synsvinkel | 70/70/50/70 (Typ.)(CR≥10) |
| respons | 15/35 (Typ.)(Tr/Td) ms |
| god udsigt kl | 6 o'clock |
| arbejdstilstand | TN, Normally White, Transmissive |
| farvedybde | 65K/262K 61% NTSC |
| baggrundsbelysning | 3S7P WLED , No Driver |
| masse | TBD |
| anvendes til | Industrial |
| opdateringshastighed | 60Hz |
| berøringsskærm | 4-wire Resistive Touch |
| Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| AM-320240N1TMQW-T30H-D(R) | AMPIRE | 5.7 | 320×240 |
| CLAA057VC01CW | CPT | 5.7 | 640×480 |
| EL320.240.36 HB | Lumineq | 5.7 | 320×240 |
| G057QTN01.1 | AUO | 5.7 | 320×240 |
| H572DAN01.2 | AUO | 5.7 | 1080×1920 |
| LQ057V3LG11 | SHARP | 5.7 | 640×480 |
| MST-G320240DBSW-213W-E | Other | 5.7 | 320×240 |
| NL6448BC18-06F | NLT | 5.7 | 640×480 |
| SP14Q001 | KOE | 5.7 | 320×240 |
| TCG057QVLAC-G00 | Kyocera | 5.7 | 320×240 |
