| Varenummer | AM-320240N1TMQW-T30H-D(R) |
| Mærke | AMPIRE |
| Størrelse | 5.7 |
| Ansøgning | IA |
| Løsning | 320×240 |
| Sammensætning | LCM |
| Lysstyrke | 400 |
| CR | 350:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | AMPIRE |
| panel model | AM-320240N1TMQW-T30H-D(R) |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 5.7 inch |
| løsning | 320(RGB)×240 , QVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 115.2×86.4 mm |
| omrids | 167×109×14.8 mm |
| overflade | |
| lysstyrke | 400 cd/m² (Typ.) |
| kontrastforhold | 350:1 (Typ.) |
| vise farver | 262K (6-bit), CIE193161% |
| responstid | 15/35 (Typ.)(Tr/Td) |
| synsvinkel | 70/70/70/50 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 3S7PWLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 6-bit), 40 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | IA |
| AM-320240N1TMQW-T30H-D(R) | AMPIRE | 5.7 | 320×240 |
| CLAA057VC01CW | CPT | 5.7 | 640×480 |
| G057VTN01.0 | AUO | 5.7 | 640×480 |
| KG057QV1CA-G01 | Kyocera | 5.7 | 320×240 |
| KS3224ASTT-FW-X20 | Kyocera | 5.7 | 320×240 |
| LQ057AC111 | Other | 5.7 | 320×240 |
| LQ057Q3DC12 | SHARP | 5.7 | 320×240 |
| LQ057V3LG11 | SHARP | 5.7 | 640×480 |
| MST-G320240DBSW-213W-E | Other | 5.7 | 320×240 |
| NL6448BC18-03F | NLT | 5.7 | 640×480 |
| EL160.80.50 ET CC | Lumineq | 3.5 | 160×80 |
| EL320.256-FD7 | Lumineq | 4.8 | 320×256 |
| G057QN01 V1 | AUO | 5.7 | 320×240 |
| G104SN02 V2 | AUO | 10.4 | 800×600 |
| G121AGE-L03 | Innolux | 12.1 | 800×600 |
| HLD0909-020010 | Hosiden | 9.0 | 640×480 |
| LM-CE53-22NEK | SANYO | 9.4 | 640×480 |
| LM-CG53-22NDK | SANYO | 10.4 | 640×480 |
| LM64C219 | SHARP | 8.0 | 640×480 |
| NL128102AC29-17 | NLT | 19.0 | 1280×1024 |
