| Varenummer | AT056TN52 V.4 |
| Mærke | Innolux |
| Størrelse | 5.6 |
| Ansøgning | CNS |
| Løsning | 640×480 |
| Sammensætning | LCM |
| Lysstyrke | |
| CR | 500:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | INNOLUX |
| panel model | AT056TN52 V.4 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 5.6 inch |
| løsning | 640(RGB)×480 , VGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 112.896×84.672 mm |
| overflade | |
| lysstyrke | |
| kontrastforhold | 500:1 (Typ.) |
| vise farver | 262K (6-bit) |
| responstid | 10/15 (Typ.)(Tr/Td) |
| synsvinkel | 70/70/50/70 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDEmbedded (LED Driver) |
| signal interface | Parallel RGB (1 ch, 6-bit) |
| indgangsspænding | 3.3V (Typ.)(VDD) |
| Ansøgning | CNS |
