| Varenummer | AT102TN03 V.8 |
| Mærke | Innolux |
| Størrelse | 10.2 |
| Ansøgning | CNS |
| Løsning | 800×480 |
| Sammensætning | LCM |
| Lysstyrke | 350 |
| CR | 300:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | INNOLUX |
| panel model | AT102TN03 V.8 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 10.2 inch |
| løsning | 800(RGB)×480 , WVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 222×132.48 mm |
| omrids | 235×145.8×6.4 mm |
| overflade | Antiglare |
| lysstyrke | 350 cd/m² (Typ.) |
| kontrastforhold | 300:1 (Typ.) |
| vise farver | 262K (6-bit), CIE193150% |
| responstid | 15/20 (Typ.)(Tr/Td) |
| synsvinkel | 65/65/45/65 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 3S10PWLEDWithout Driver |
| signal interface | TTL (1 ch, 6-bit), 60 pins |
| indgangsspænding | 3.3/9.2/16/-7V (Typ.)(VCC/AVDD/VGH/VGL) |
| Ansøgning | CNS |
| AM-800480RSTMQW-TA1H | AMPIRE | 7.0 | 800×480 |
| C070VW04 V2 | AUO | 7.0 | 800×480 |
| C070VW04 V7 | AUO | 7.0 | 800×480 |
| G080Y1-T01 | Innolux | 8.0 | 800×480 |
| LA080WV1-TD01 | LG Display | 8.0 | 800×480 |
| LQ065T5GG63 | SHARP | 6.5 | 400×234 |
| LQ080T5GG01B | SHARP | 8.0 | 480×234 |
| PW070XUA | E Ink | 7.0 | 480×234 |
| T-51965GD088ZU-MFW-AEN | Kyocera | 8.8 | 640×240 |
| TJ123NP01CA | Innolux | 12.3 | 1280×480 |
