| Varenummer | B131RW02 V0 |
| Mærke | AUO |
| Størrelse | 13.1 |
| Ansøgning | NBPC |
| Løsning | 1600×900 |
| Sammensætning | LCM |
| Lysstyrke | 410 |
| CR | 500:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | eDP |
| panel mærke | AUO |
| panel model | B131RW02 V0 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 13.1 inch |
| løsning | 1600(RGB)×900 , HD+ |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 289.2×162.675 mm |
| omrids | 299.1×184.3×3 mm |
| form stil | Slim (PCBA Flat, Depth ≤3.2mm) |
| overflade | Antiglare, Hard coating (4H) |
| lysstyrke | 410 cd/m² (Typ.) |
| kontrastforhold | 500:1 (Typ.) |
| vise farver | 262K (6-bit), CIE193181% |
| responstid | 3/13 (Typ.)(Tr/Td) |
| synsvinkel | 55/55/50/55 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDWithout Driver |
| signal interface | eDP (2 Lanes), 30 pins |
| indgangsspænding | 2.5V (Typ.) |
| Ansøgning | NBPC |
