| Varenummer | B140QAN02.2 |
| Mærke | AUO |
| Størrelse | 14.0 |
| Ansøgning | Laptop |
| Løsning | 2560×1440 |
| Sammensætning | LTPS TFT-LCD, LCM |
| Lysstyrke | |
| CR | 1500:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | eDP |
| panel mærke | AUO |
| panel model | B140QAN02.2 |
| panelstørrelse | 14.0" |
| paneltype | LTPS TFT-LCD, LCM |
| løsning | 2560(RGB)×1440, Quad-HD, 210PPI |
| pixel format | RGB Vertical Stripe |
| udstillingsområde | 309.35(W)×174.01(H) mm |
| bezel åbning | - |
| konturstørrelse | 315.05(W)×195.6(H) ×2.4(D) mm |
| overflade | Hard coating (3H) |
| lysstyrke | - |
| kontrastforhold | 1500:1 (Typ.) (TM) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10) |
| visningstilstand | AHVA, Normally Black, Transmissive |
| bedste udsigt på | Symmetry |
| responstid | 25 (Typ.)(Tr+Td) |
| vise farver | 16.7M |
| lampe type | WLED , 15K hours , With LED Driver |
| frekvens | 60Hz |
| berøringsskærm | Without |
| form stil | Slim (PCBA Flat, T≤3.2mm) |
| Ansøgning | Laptop |
| signal interface | eDP (4 Lanes) Connector |
| indgangsspænding | 3.3V (Typ.) |
| miljø | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
