| Varenummer | B140QAN01.0 |
| Mærke | AUO |
| Størrelse | 14.0 |
| Ansøgning | NBPC |
| Løsning | 2560×1440 |
| Sammensætning | LCM |
| Lysstyrke | 340 |
| CR | 700:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | eDP |
| panel mærke | AUO |
| panel model | B140QAN01.0 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 14.0 inch |
| løsning | 2560(RGB)×1440 , Quad-HD |
| visningstilstand | AHVA, Normally Black, Transmissive |
| aktivt område | 309.35×174.01 mm |
| omrids | 320.4×205.1×2.6 mm |
| form stil | Slim (PCBA Flat, Depth ≤3.2mm) |
| overflade | Hard coating (3H) |
| lysstyrke | 340 cd/m² (Typ.) |
| kontrastforhold | 700:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193172% |
| responstid | 25 (Typ.)(Tr+Td) |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDEmbedded (LED Driver) |
| signal interface | eDP (4 Lanes), 40 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | NBPC |
