| Varenummer | B141PW04 V0 HW1A |
| Mærke | AUO |
| Størrelse | 14.1 |
| Ansøgning | NBPC |
| Løsning | 1440×900 |
| Sammensætning | LCM |
| Lysstyrke | 280 |
| CR | 350:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | AUO |
| panel model | B141PW04 V0 HW1A 3 Compatible model |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 14.1 inch |
| løsning | 1440(RGB)×900 , WXGA+ |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 303.48×189.675 mm |
| omrids | 319.5×206.5×5.5 mm |
| form stil | Wedge (PCBA Bent, Depth ≥5.2mm) |
| overflade | Antiglare (Haze 11%), Hard coating (3H) |
| lysstyrke | 280 cd/m² (Typ.) |
| kontrastforhold | 350:1 (Min.) |
| vise farver | 262K (6-bit) |
| responstid | 8 (Typ.)(Tr+Td) |
| synsvinkel | 40/40/15/30 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDEmbedded (LED Driver) |
| signal interface | LVDS (2 ch, 6-bit), 50 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | NBPC |
| B141EW04 V5 | AUO | 14.1 | 1280×800 |
| B141PW04 V0 HW0A | AUO | 14.1 | 1440×900 |
| B141PW04 V0 HW1A | AUO | 14.1 | 1440×900 |
| B141PW04 V0 HW2A | AUO | 14.1 | 1440×900 |
| B141PW04 V1 HW0A | AUO | 14.1 | 1440×900 |
| LP141WX3-TLA3 | LG Display | 14.1 | 1280×800 |
| LP141X2 | LG Display | 14.1 | 1024×768 |
| LTM14C421F | TOSHIBA | 14.1 | 1024×768 |
| LTN141AT09-301 | Samsung | 14.1 | 1280×800 |
| LTN141XB-L02 | Samsung | 14.1 | 1024×768 |
| B140HAN01.2 | AUO | 14.0 | 1920×1080 |
| B156XTN02.2 | AUO | 15.6 | 1366×768 |
| LP133WF6-SSA1 | LG Display | 13.3 | 1920×1080 |
| LP141WX1-TL02 | LG Display | 14.1 | 1280×800 |
| LP154WP4-TLA1 | LG Display | 15.4 | 1440×900 |
| LQ141X1LH03 | SHARP | 14.1 | 1024×768 |
| LTN141X8-L00 | Samsung | 14.1 | 1024×768 |
| LTN150PF-L02 | Samsung | 15.0 | 1400×1050 |
| LTN156HT01-101 | Samsung | 15.6 | 1920×1080 |
| NT156WHM-N10 | BOE | 15.6 | 1366×768 |
