| Varenummer | B170UW01 V0 |
| Mærke | AUO |
| Størrelse | 17.0 |
| Ansøgning | NBPC |
| Løsning | 1920×1200 |
| Sammensætning | LCM |
| Lysstyrke | 260 |
| CR | 600:1 |
| Farver | 262K |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | AUO |
| panel model | B170UW01 V0 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 17.0 inch |
| løsning | 1920(RGB)×1200 , WUXGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 367.2×229.5 mm |
| omrids | 382.2×243.3×6.6 mm |
| form stil | Wedge (PCBA Bent, Depth ≥5.2mm) |
| overflade | Glare (Haze 0%), Hard coating (4H) |
| lysstyrke | 260 cd/m² (Typ.) |
| kontrastforhold | 600:1 (Typ.) |
| vise farver | 262K (6-bit), CIE193145% |
| responstid | 8 (Typ.)(Tr+Td) |
| synsvinkel | 70/70/60/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 1 pcsCCFLWithout Driver |
| signal interface | LVDS (2 ch, 6-bit), 30 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | NBPC |
| B170UW01 V0 | AUO | 17.0 | 1920×1200 |
| B170UW02 V0 | AUO | 17.0 | 1920×1200 |
| CLAA170ES01E | CPT | 17.0 | 1280×1024 |
| LQ170M1LA4B | SHARP | 17.0 | 1920×1200 |
| LTN170BT09-001 | Samsung | 17.0 | 1440×900 |
| LTN170BT11-D03 | Samsung | 17.0 | 1440×900 |
| LTN170CT07-G01 | Samsung | 17.0 | 1920×1200 |
| LTN170CT08-001 | Samsung | 17.0 | 1920×1200 |
| M170E8-L01 | Innolux | 17.0 | 1280×1024 |
| TD170WGCB2 | TPO | 17.0 | 1280×1024 |
| B140XTT01.0 | AUO | 14.0 | 1366×768 |
| B140XW02 V1 | AUO | 14.0 | 1366×768 |
| CLAA141WB05A | CPT | 14.1 | 1280×800 |
| LP150E07-A3 | LG Display | 15.0 | 1400×1050 |
| LP154WX7-TLA1 | LG Display | 15.4 | 1280×800 |
| LP171WU1-TLA7 | LG Display | 17.1 | 1920×1200 |
| LP173WD1-TLC2 | LG Display | 17.3 | 1600×900 |
| LQ106K1LA01B | SHARP | 10.6 | 1280×768 |
| LTD133EQ1B | TOSHIBA | 13.3 | 1280×800 |
| LTN141W1-L04 | Samsung | 14.1 | 1280×800 |
