| Varenummer | CLAA141WB05A |
| Mærke | CPT |
| Størrelse | 14.1 |
| Ansøgning | NBPC |
| Løsning | 1280×800 |
| Sammensætning | LCM |
| Lysstyrke | 200 |
| CR | 500:1 |
| Farver | 262K |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | CPT |
| panel model | CLAA141WB05A 13 Compatible model |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 14.1 inch |
| løsning | 1280(RGB)×800 , WXGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 303.74×189.84 mm |
| omrids | 319.5×205.5×5.5 mm |
| form stil | Wedge (PCBA Bent, Depth ≥5.2mm) |
| overflade | Antiglare (Haze 12%), Hard coating (3H) |
| lysstyrke | 200 cd/m² (Typ.) |
| kontrastforhold | 500:1 (Typ.) |
| vise farver | 262K (6-bit) |
| responstid | 5/11 (Typ.)(Tr/Td) |
| synsvinkel | 40/40/20/40 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 1 pcsCCFLWithout Driver |
| signal interface | LVDS (1 ch, 6-bit), 30 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | NBPC |
| B141EW05 V0 | AUO | 14.1 | 1280×800 |
| CLAA140UA01 CN | CPT | 14.0 | 1600×900 |
| CLAA140WA01 | CPT | 14.0 | 1280×768 |
| CLAA140WB01A | CPT | 14.0 | 1366×768 |
| CLAA140WB11A | CPT | 14.0 | 1366×768 |
| CLAA141WB05A | CPT | 14.1 | 1280×800 |
| CLAA141WB11 | CPT | 14.1 | 1280×800 |
| LP141WP1-TLC1 | LG Display | 14.1 | 1440×900 |
| LP141WX3-TLA3 | LG Display | 14.1 | 1280×800 |
| LP141WX5-TLC1 | LG Display | 14.1 | 1280×800 |
| HV150UX1-101 | HYDIS | 15.0 | 1600×1200 |
| LP125WH2-TLE1 | LG Display | 12.5 | 1366×768 |
| LP133WX2-TLG1 | LG Display | 13.3 | 1280×800 |
| LP141X13-B1 | LG Display | 14.1 | 1024×768 |
| LP171WX2-A4K7 | LG Display | 17.1 | 1440×900 |
| LTN125AT02-301 | Samsung | 12.5 | 1366×768 |
| LTN156AT15-W01 | Samsung | 15.6 | 1366×768 |
| LTN156AT16-401 | Samsung | 15.6 | 1366×768 |
| N133BGE-EAB | Innolux | 13.3 | 1366×768 |
| N156O6-L01 | Innolux | 15.6 | 1600×900 |
