| Varenummer | BH156EA2S |
| Mærke | No Brand |
| Størrelse | 15.6 |
| Ansøgning | Laptop |
| Løsning | 1920×1080 |
| Sammensætning | Oxide TFT-LCD , LCM |
| Lysstyrke | |
| CR | 1000:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | eDP |
| mærke | No Brand |
| diagonal størrelse | 15.6 inch |
| pixel format | 1920(RGB)×1080 [FHD] 141PPI |
| aktivt område | 344.16(H)×193.59(V) mm |
| bezel område | - |
| luminans | 250 cd/m² (Typ.) |
| visningsretning | Symmetry |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10) |
| støtte farve | 262K 45% NTSC |
| form stil | Slim (PCBA Flat, T≤3.2mm) |
| billedhastighed | 60Hz |
| interface type | eDP (2 Lanes) , 30 pins Connector |
| Strømforsyning | 3.3V (Typ.) |
| miljø | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| model | BH156EA2S |
| type | Oxide TFT-LCD , LCM |
| konfiguration | RGB Vertical Stripe |
| omrids dim. | 359.5(H)×223.8(V) ×3.2(D) mm |
| behandling | Antiglare |
| kontrastforhold | 1000:1 (Typ.) (TM) |
| responstid | 25 (Typ.)(Tr+Tf) |
| driftstilstand | FFS, Normally Black, Transmissive |
| lyskilde | WLED [4S10P] , 10K hours , With LED Driver |
| designet til | Laptop |
| berøringspanel | Without |
| B156XTN03.2 | AUO | 15.6 | 1366×768 |
| CLAA156WA01A | CPT | 15.6 | 1366×768 |
| CLAA156WA11A | CPT | 15.6 | 1366×768 |
| LP156WF4-SPB1 | LG Display | 15.6 | 1920×1080 |
| LP156WF6-SPK1 | LG Display | 15.6 | 1920×1080 |
| LTN156AT32-L01 | Samsung | 15.6 | 1366×768 |
| LTN156HT02-B01 | Samsung | 15.6 | 1920×1080 |
| N156B6-L3D | Innolux | 15.6 | 1366×768 |
| N156HGE-LA1 | Innolux | 15.6 | 1920×1080 |
| TMS156WX1-02TC | Tianma | 15.6 | 1366×768 |
